Product Description:
Workshop Welding Fume Extractor 99.9% Filtration Grade Industry Fume Extractor For Welding
The Weld Fume Extraction Unit is a powerful solution designed to effectively remove welding fumes and smoke from the air, providing a safe and clean working environment for welders. This Weld Fume Extractor is equipped with a single arm airflow system that can efficiently handle airflow ranging from 2000 to 2500m3/h, ensuring the capture and extraction of fumes at the source.
When it comes to filtration efficiency, this Weld Fume Extractor boasts an impressive 99.9% efficiency rate, ensuring that even the smallest particles and contaminants are effectively captured and filtered out, promoting a healthier work environment.
Features:
1. Advanced Motor
We use CE certified motor for all model (motor CE certificate is available, please request from sales), it's the top-level motors on the international market.
2. Overload Protection
The machine is adopted overload protection circuit, can effectively prevent overload and short circuit, which can make the machine has high security and stable performance.
For high-end users, we could use Schneider electrical components (such as Breaker, AC contactor), to guarantee user's absolute safety.
3. High Temperature Resistant Suction Hose
A suction hose with a high temperature resistance of 400℃ is available, which provides better fire resistance and safety.
4. Advanced External Articulated Arm
The external articulated arm can hover at any position in the space and rotate freely, bring very small resistance during suction.
5. A Variety of Suction Arm Designs Accept Customization
1) Optional 2.5m and 3m telescopic suction arms can be equipped according to needs.
2) 3 stage Nederman style arm could be installed on our machine.
6. Extraction Hood Customizable
The Extraction Hood shape can be customized, such as U shaped, Hat shape, Taper shape, or other special shape.
7. Function Extension Available
Flame screen, Working spotlight, Smoke sensor and Temperature sensor.
8. Polyester Fiber Cartridge Filter
Membrane-covered filter material is adopted to block large particles of smoke and dust. The filtration density is greater than 99%.
Technical Parameters:
| Model | Structure | Air Flow | Filter Area | Power | Cartridge Filter size &
quantity | Selfcleaning Mode | Overall Size
(L*W*H) |
| WFP-QD-SOS25 | Single Extraction Arm | 480m³/h | 4m³ | 0.25KW | Φ325*300*1 set | Manual operation | 380*405*507mm |
| WFP-QD-SSC220 | Single Extraction Arm | 1500m³/h | 12m³ | 1.1KW | Φ325*300*1 set | Manual operation | 460*480*890mm |
| WFP-QD-SBC11 | Single Extraction Arm(Big Body) | 1500-2000m³/h | 12m³ | 1.1KW | φ325*500*1 set | Fully automatic cleaning
(Compressed air pulse jet) | 500*700*1000mm |
| WFP-QD-SFB20 | Single Extraction Arm | 2000-2500m³/h | 16m³ | 2.2KW | φ325*300*1 set | Manual operation | 530*670*1040mm |
| WFP-QD-SBC30 | Single Extraction Arm(Big Body) | 2000-2500m³/h | 16m³ | 2.2KW | Φ325*500*1 set | Fully automatic cleaning
(Compressed air pulse jet) | 500*700*1000mm |
| WFP-QD-WSC12 | Double Extraction Ams | 2500m²/h | 24m² | 2.2KW | φ325*300*2 sets | Manual operation | 530*670*1040mm |
| WFP-QD-WBC22 | Double Extraction
Arms(Big Body) | 2500m²/h | 24m³ | 2.2KW | Φ325*500*2 sets | Fully automatic cleaning
(Compressed air pulse jet) | 750*800*1200mm |
| WFP-QD-WFB30 | Double Extraction
Arms(Big Airflow) | 3000m²/h | 32m³ | 3KW | φ325*300*2 sets | Manual operation | 530*670*1040mm |
| WFP-QD-WFB45 | Double Extraction
Arms(Big Airflow,
Big body) | 3000m³/h | 32m³ | 3KW | Φ325*500*2 sets | Fully automatic cleaning
(Compressed air pulse jet) | 750*800*1200mm |
Applications:
- Mining
- Printing
- All metal welding
- Laser cutting and engraving
- Heavy equipment manufacturing
- Maintenance and repair operations
- Other smog-producing industries
We provide permanent after-sales service! Use our workshop welding fume extractor to create a healthy and safe working environment for your workers now!
